Features
1. Maximum support of 40 zones, 16 groups of 433MHz remote control: with 8 wired zones and 32 wireless zones, 32 wired zones can be extended through RS-485.
2 With 2 programmable output and an alarm output.Can be extended to 40 programmable linkage relay outputs through RS-485,
3. It support 6 groups of scheduled arming and disarming function, support Monday to Sunday optional;
The system is equipped with clock chip, and the power failure time continues to run.
4. Support 1 administrator password and 1 programming password, 1 group of hijacked passwords, 16 user passwords, and 40 arming/disarming passwords.
5. Support access to 1 GPRS center, 3 call centers, and 8 SMS and telephone alarm Numbers.Through the alarm phone and SMS, the user can receive the alarm information, or the host can control the process.
6.The system supports the black box function, which can save the latest 6000 records, alarm records and operation records respectively.Support access to RS232 serial printer to realize real-time alarm printing.
7.Voice navigation broadcast in the whole programming operation.
|
Power Supply |
DC13.8V |
|
Standby battery |
12V7AH lead-acid battery |
|
Auxiliary output |
DC12V500mA |
|
Static Current |
300mA |
|
Alarm status |
≥1000mA (subject to Outdoor siren and other external equipment) |
|
Alarm outlet |
DC12V500mA |
|
Programmable output |
DC12V200mA |
|
Wired zones |
2.2 KΩ |
|
Wireless parameters |
433 MHZ, encoded mode 1527, shock resistance 220 KΩ |
|
Operating temperature |
-10~55℃ |
|
Case size |
255*265*88mm |
|
Keypad size |
161*120*28mm |
|
Weight |
≥3kg |
|
|
|
